Engine
Type:
Air-cooled, 4-stroke, SOHC, single-cylinder
Displacement:
124.86 cc
Bore x Stroke:
52.4 mm x 57.9 mm
Compression Ratio:
11.0:1
Maximum Power:
Approximately 8.1 hp (6.0 kW) at 6,500 rpm
Maximum Torque:
Approximately 10.4 Nm at 5,000 rpm
Fuel System:
Fuel injection
Ignition System:
TCI (Transistor Controlled Ignition)
Cooling System:
Air-cooled
Transmission:
V-belt automatic
Dimensions
Overall Length:
1,820 mm
Overall Width:
685 mm
Overall Height:
1,145 mm
Seat Height:
790 mm
Wheelbase:
1,280 mm
Ground Clearance:
125 mm
Fuel Tank Capacity:
4.4 liters
Kerb Weight:
Approximately 100 kg
Suspension
Front:
Telescopic fork
Rear:
Unit swing
Brakes
Front:
Disc brake
Rear:
Drum brake
Tires
Front:
110/70-12
Rear:
110/70-12
Electrical System
Battery:
12V, 6Ah
Lighting:
Full LED lighting system
Additional Features
Underseat Storage Capacity:
27 liters
