Engine
Type:
157cc, single-cylinder, liquid-cooled, four-stroke
Valve Train:
SOHC, 4 valves
Bore x Stroke:
60.0 mm x 55.5 mm
Compression Ratio:
12.0:1
Maximum Power:
11.3 kW (15.2 HP) @ 8,500 RPM
Maximum Torque:
13.8 Nm @ 7,000 RPM
Fuel System:
PGM-FI electronic fuel injection
Ignition:
Full transistorized
Starter:
Electric (ACG starter)
Transmission
Type:
Automatic, V-Matic belt drive
Dimensions and Weight
Overall Length:
1,929 mm
Overall Width:
678 mm
Overall Height:
1,088 mm
Wheelbase:
1,278 mm
Seat Height:
778 mm
Ground Clearance:
138 mm
Curb Weight:
116 kg
Fuel Capacity
Tank Capacity:
5.5 liters
Fuel Consumption:
Approximately 46.7 km/L
Brakes and Suspension
Front Brake:
Hydraulic disc with ABS
Rear Brake:
Mechanical leading trailing (drum)
Front Suspension:
Telescopic fork
Rear Suspension:
Monoshock
Tires
Front Tire:
100/80-14 M/C 48P (Tubeless)
Rear Tire:
120/70-14 M/C 61P (Tubeless)
Frame
Type:
Underbone
Additional Features
Lighting:
Full LED headlight and taillight
Instrumentation:
Digital display
Convenience:
Smart Key System with answer-back and anti-theft alarm
Safety:
Front ABS to prevent wheel lock during sudden braking
