Engine
Type:
Liquid-cooled, 4-stroke, parallel twin-cylinder, DOHC
Displacement:
649 cc
Bore x Stroke:
83 x 60 mm
Compression Ratio:
10.8:1
Fuel System:
Digital Fuel Injection (DFI) with 36 mm throttle bodies
Ignition:
Transistorized with electronic advance
Starting System:
Electric
Maximum Power:
Approximately 67.3 hp (50.2 kW) at 8,500 rpm
Maximum Torque:
Approximately 65.7 Nm at 6,500 rpm
Transmission
Gearbox:
6-speed constant mesh
Final Drive:
O-ring-sealed chain
Clutch:
Wet multi-disc, manual
Dimensions
Overall Length:
2,055 mm
Overall Width:
740 mm
Overall Height:
1,135 mm
Wheelbase:
1,410 mm
Ground Clearance:
130 mm
Seat Height:
790 mm
Wet Weight:
193 kg
Fuel Tank Capacity:
15 liters
Suspension
Front:
41 mm hydraulic telescopic fork
Rear:
Horizontal back-link with adjustable preload
Brakes
Front:
Dual 300 mm petal discs with dual-piston calipers
Rear:
Single 220 mm petal disc with single-piston caliper
Tires
Front:
120/70-ZR17
Rear:
160/60-ZR17
