Engine
Type:
Single-cylinder, 4-stroke, DOHC
Displacement:
149.16 cc
Bore x Stroke:
57.3 x 57.8 mm
Compression Ratio:
11.3:1
Cooling System:
Liquid-cooled
Fuel System:
Electronic Fuel Injection (EFI)
Ignition:
Transistorized Coil Ignition
Starting System:
Electric
Maximum Power:
Approximately 16 hp (12 kW)
Maximum Torque:
Approximately 13.7 Nm
Transmission
Gearbox:
6-speed constant mesh
Final Drive:
Chain
Clutch:
Wet multiplate
Dimensions
Overall Length:
1,973 mm
Overall Width:
802 mm
Overall Height:
1,077 mm
Wheelbase:
1,310 mm
Ground Clearance:
160 mm
Seat Height:
782 mm
Wet Weight:
139 kg
Fuel Tank Capacity:
12 liters
Suspension
Front:
41 mm upside-down (USD) telescopic fork
Rear:
Pro-Link monoshock with adjustable preload
Brakes
Front:
Single 296 mm disc with dual-piston caliper
Rear:
Single 220 mm disc with single-piston caliper
ABS:
Dual-channel Anti-lock Braking System (ABS)
Tires
Front:
100/80-17
Rear:
130/70-17
